Features
●High efficiency, low resistance
●Light weight, convenient installation
●Adjustable volume, vacuum sealed
●Using circular tube or spiral duct connection, suitable for clean room dry sealed condole
Materials and operating conditions
●External frane：Aluminum alloy frame
●Over the roof: galvanized or cooling-plate pensu
●Sealant：Gel-glue ●Filter media：Hot-melt
●Gasket：EVA ●Filter media：Glass fiber
●Use the highest temperature, humidity：80℃、80%
(Standard specification)
|
model |
Outside dimensions (mm) |
Rated air flow (m3/h) |
Imitial resistance (Pa) |
Efficiency (%) |
Dust capacity (g) |
|
CJ-FK-D1 |
610×610×150 |
1000 |
≤220 |
≥99.99 |
600 |
|
CJ-FK-D2 |
915×610×150 |
1500 |
≤220 |
≥99.99 |
900 |
|
CJ-FK-D3 |
1220×610×150 |
2000 |
≤220 |
≥99.99 |
1200 |
*According to the requirements of users can make different specifications of integration draught
